King Chain #3 Twist Link Machine Chain, Sold Per Foot
*Online Pricing Only
King Chain #3 Twist Link Machine Chain
Twist link machine chain has each link turned ninety degrees to its neighbour, so the chain lies flat against a surface instead of standing on edge. That is why it turns up on welding carts, tool boards and anywhere the chain runs along something rather than hanging free.
Machine chain is a utility chain. It is not for load securement on a vehicle and not for overhead lifting.
- 255 lb. working load limit
- 1,020 lb. minimum breaking force
- Lies flat against a surface instead of standing on edge
- 0.135 in. material diameter, 0.56 in. nominal inside length, 0.20 in. nominal inside width
- Cut to the linear foot
- Model 527362
Specifications
| Specification | Value |
|---|---|
| Material diameter | 0.135 in. |
| Working load limit | 255 lb. |
| Minimum breaking force | 1,020 lb. |
| Nominal inside length | 0.56 in. |
| Nominal inside width | 0.20 in. |
| Overhead lifting | Not permitted |
| Model | 527362 |
Questions
How much can it hold?
255 lb. working load limit.
What is twist link for?
The links are turned so the chain lies flat rather than on edge. It sits neatly against a surface and does not roll.
Twist link or straight link?
Twist link lies flat. Straight link runs better through a pulley or guide and is marginally stronger at the same trade size.
Can I lift with it?
No.
Specifications and load ratings are provided for reference only; please verify with the manufacturer before use in load-bearing or safety-critical applications.
